tree Command in Linux: Display Directory Structure

The ls command shows the contents of one directory at a time. When you want to see how a whole project is laid out, running ls in every subdirectory gets old fast. The tree command solves this by listing a directory and everything below it as an indented tree, so you can take in the entire hierarchy at a glance.

This guide explains how to install tree and use it to display directory structures, limit depth, filter files, show sizes, and save the output to a file.

Installing tree #

tree is a small utility that is not installed by default on most distributions, but it is available in the standard repositories.

On Ubuntu, Debian, and derivatives:

sudo apt update
sudo apt install tree

On Fedora, RHEL, and derivatives:

sudo dnf install tree

Once installed, verify the version:

tree --version

Basic Usage #

The general syntax of the tree command is as follows:

tree [OPTIONS] [DIRECTORY]

When invoked without arguments, tree lists the current directory recursively. For example, running it inside a small Node.js project produces output like this:

tree

.
├── package.json
├── README.md
└── src
    ├── app.js
    └── utils
        └── helpers.js

3 directories, 4 files

Each level of nesting is indented and connected with line-drawing characters, so helpers.js is clearly inside src/utils. The report line at the bottom counts everything in the listing, and since tree 2.1 that count includes the starting directory itself.

To list a different directory, pass its path as an argument:

tree /etc/nginx

Limiting the Depth #

On a large directory the default recursive listing can print thousands of lines. The -L option limits how many levels deep tree descends:

tree -L 2 /var/log

With -L 2, tree shows the contents of /var/log and one level of subdirectories, then stops. This is usually the first option to reach for when a plain tree floods the terminal.

Showing Hidden Files #

Like ls, tree skips hidden files by default. Use -a to include entries that start with a dot:

tree -a

.
├── .env
├── .git
│   ├── config
│   └── HEAD
├── package.json
├── README.md
└── src
    ├── app.js
    └── utils
        └── helpers.js

4 directories, 7 files

Notice that .env and the .git directory now show up in the listing. Combining -a with -L 1 is a quick way to audit what actually lives in a directory, dotfiles included.

Listing Directories Only #

When you only care about the folder structure and not the files, use -d:

tree -d

.
└── src
    └── utils

3 directories

The files are gone and only the directory skeleton remains, which is handy for documenting a project layout.

Displaying File Sizes #

The -s option prints the size of each file in bytes. In practice you will almost always use -h instead, which prints the sizes in human-readable units:

tree -h

[4.0K]  .
├── [ 412]  package.json
├── [1.2K]  README.md
└── [4.0K]  src
    ├── [3.4K]  app.js
    └── [4.0K]  utils
        └── [ 890]  helpers.js

3 directories, 4 files

The size shown next to a directory is the size of the directory entry itself, not its contents. To get cumulative directory sizes, add --du:

tree --du -h

With --du, each directory reports the total size of everything inside it, similar to the du command . This option reads the full hierarchy before printing, so it can take time and consume extra memory on a large directory tree.

Filtering by Pattern #

The -P option lists only files that match a wildcard pattern. Quote the pattern so the shell does not expand it first:

tree -P "*.js"

Directories are still shown even when they contain no matching files. Add --prune to remove the empty branches:

tree -P "*.js" --prune

.
└── src
    ├── app.js
    └── utils
        └── helpers.js

3 directories, 2 files

Only the JavaScript files and the directories that lead to them remain. The patterns follow the same rules as shell globs; see our guide to Linux wildcards and globbing for the full syntax.

The -I option does the opposite and excludes matching entries. Multiple patterns are separated with |:

tree -I "node_modules|.git"

This is the most common tree invocation in day-to-day work, since it hides the noise of dependency and VCS directories. In tree 2.0 and later you can also pass --gitignore to skip everything that the project’s .gitignore files exclude.

Printing Full Paths #

By default each entry shows only its own name. The -f option prints the full path prefix instead:

tree -f src

src
├── src/app.js
└── src/utils
    └── src/utils/helpers.js

2 directories, 2 files

Full paths are useful in saved listings because each entry keeps its context even when you view the output away from the original directory.

Sorting the Output #

Entries are sorted alphabetically by default. The most useful alternatives are:

• -t - Sort by last modification time, oldest first.
• -r - Reverse the current sort order.
• -v - Sort version strings naturally, so file2 comes before file10.
• --sort=size - Sort by file size.

Note that -t places the oldest entries first, which is the opposite of what ls -t does. To see the most recently modified files at the top of each directory, combine it with -r:

tree -t -r

Saving the Output to a File #

The -o option writes the tree to a file instead of the terminal:

tree -o structure.txt

The line-drawing characters are UTF-8 by default. If the file is destined for an environment that cannot render them, force plain ASCII connectors:

tree --charset=ascii -o structure.txt

tree can also emit structured formats directly: -J produces JSON, -X produces XML, and -H <baseHref> produces a browsable HTML listing:

tree -J -L 2 > structure.json

Quick Reference #

Conclusion #

The tree command turns a nested directory hierarchy into a single readable listing, and options such as -L, -I, and --du keep the output focused on what you actually need. If you want the same tree-style view for running processes instead of files, take a look at the pstree command .
